Pogo is an elastodynamic finite element solver developed by members of the NDE lab. Pogo is high speed, using Nvidia graphics cards to produce results up to 100 times faster than CPU-based alternatives. The software can be used for a variety of problems in elastodynamics, including ultrasonic and geophysical modelling.

More information on Pogo can be found on our website http://www.pogo.software/







Benefits

railmeshThe finite element method is a very powerful, general approach. The ability of FE to mesh arbitrary geometries makes it well suited to NDE applications, where the complexity of both the components and defects must be considered for accurate results.

  • Large models (in the group we have now run models exceeding 1.2 billion degrees of freedom in 3D and 3.2 in 2D)
  • Parametric studies – run many models quickly and see how the results vary
  • Monte Carlo evaluations – build up statistical models of behaviour by running many cases from a distribution











System requirements

pcbanglePogo requires Nvidia GPUs of compute version 3.0 and above (all new Nvidia cards sold these days satisfy this). This is not restricted to large workstations (although the best performance can be achieved from these!) – Pogo will run on a simple laptop. Linux is most widely used for these applications, but Windows versions can also be provided.









Further Information

All questions and comments should be addressed to the author:

Dr Peter Huthwaite
p.huthwaite@imperial.ac.uk
Non-destructive testing
Department of Mechanical Engineering
Imperial College
Exhibition Road
London SW7 2AZ
