Food engineering

Aeration of confectionery products via nozzle-based injection

Ross Winter, Maria CharalambidesYannis Hardalupas

Bubble inclusions in confectionery products impart a desirable mouth-feel and unique sensory properties. This project studies the inclusion of bubbles through a novel nozzle-based injection method. The relationship between the operational/process parameters, the flow regime upstream of the nozzle and the downstream size distribution, is studied using a model air-water mixture.

AerationAeration

Fig 1- Bubbly and Churn Flow regimes upstream of the aeration nozzle

Extrusion of unleavened bread dough: experiments and simulations

M.A. (Fendi) P. Mohammed, Leonard Wanigassoriya, Maria Charalambides

An experimental and numerical study on ram extrusion of bread dough was conducted in order to develop predictive models for the pressures involved, as well as the deformation of the extruded dough. Such studies are needed as high pressures can potentially lead tosignificant degassing, tearing, and shearing of the dough and hence poor bread quality; the latter limits the use of extrusion processes which would otherwise be a cost-effective forming process. A laboratory extrusion rig was designed, with dies of varying angles and exit radii. A simulation of extrusion was performed to predict the extrusion pressure as well as the extrudate swell, as a function of die geometry and extrusion rate. Static zones were observed both experimentally and numerically.

Experimental extrusion rig. Evidence of static zones forming from pile-up of paint markers.
Experimental extrusion rig. Evidence of static zones forming from pile-up of paint markers.

Simulation of food oral processing

The stress-strain and toughness data are used in FE models to simulate food breakdown – the viscoplastic material model is implemented. Hard foods often display low ductility and toughness while they require high bite loads. Chewy foods undergo high deformations and display high fracture toughness.



oral food processingoral food processingoral food processing

oral food processing

Mechanical analysis and modelling the sheeting process of baked dough

Shirley Echendu, Wenfeng Xiao, Maria Charalambides

A predictive tool is developed for the analysis of the industrial rolling/sheeting process of dough through the characterisation of viscoelastic behaviour of selected dough samples, and simulation of sheeting process using a combination of experimental, analytical and computational (FEA) methods.

Sheeting

Sheeting

Mechanics of crushable food foams

Maria Charalambides, J Gordon Williams, Idris Kevin Mohammed, Saba Butt

The aim of this research was to predict and simulate the material deformation of confectionery wafers using the finite element method so as to improve the manufacturing process and increase efficiency on the assembly line. This was done experimentally, analytically and numerically at both the macroscopic and microscopic level. The impact of this was research can also be used to correlate the mechanical response and sensory perception of confectionery products.

Scanning Electron Micrograph of the cross-section of a confectionery wafer showing its sandwich structure
Scanning Electron Micrograph of the cross-section of a confectionery wafer showing its sandwich structure

The equations used to calculate the skin and core moduli in compression and bending
The equations used to calculate the skin and core moduli in compression and bending

wafers



Fracture/ Cutting of Soft Solids

Cutting of soft solids

Christos Skamniotis, Yatish Patel, Maria Charalambides

Cutting is an important process in the food industry, whether this on the process line or a process that occurs during consumption. The group has performed a wide range of cutting tests suitable for soft foods, including wire cutting (of cheese or gels) or blade cutting (of cheese or petfoods). The aim is to extract the intrinsic fracture toughness from such cutting data. The results are validated through alternative fracture tests such the conventional Single Edge Notch Bend tests or the Essential Work of Fracture tests. Computational models are developed to simulate the cutting process in these soft solids using cohesive zone models.

Orthogonal Blade cutting of starch based food
Orthogonal Blade cutting of starch based food

Cutting











Fracture experimental methodology 1

Fracture Experimental Methodology 1

Fracture Experimental Methodology

C.G. Skamniotis, M.A. Kamaludin, M. Elliott, M.N. Charalambides

Determining fracture toughness for soft, highly dissipative, solids has been a challenge for several decades. Amongst the limited experimental options for such materials is the essential work of fracture (EWF) method. However, EWF data are known to be strongly influenced by specimen size and test speed. In contrast to time-consuming imaging techniques that have been suggested to address such issues, a simple and reproducible method is proposed. The method accounts for diffuse dissipation in the specimen while ensuring consistent strain rates by scaling both the sample size and testing speed with ligament length.We compare this new method to current practice for two polymers: a starch based food and a polyethylene (PE) tape. Our new method gives a size independent and more conservative fracture toughness. It provides key-data, essential in numerical models of the evolution of structure breakdown in soft solids as seen for example during oral processing of foods.

A novel essential work of fracture experimental methodology for highly dissipative materials

"A novel essential work of fracture experimental methodology for highly dissipative materials", C.G. Skamniotis, M.A. Kamaludin, M. Elliott, M.N. Charalambides

Particulate composites

Micromechanical modelling in high filled particulate polymeric composites

Rouyu Zhang, Muhammed Iqbal Chatta, Hari Arora, Ed Tarleton, Joanna Li-Mayer and Maria Charalambides

Particulate polymeric composites are materials which consist of rigid particles held in a polymer based matrix, PMMA/ATH and polymer bonded explosives are examples of such materials. The aim of this research is to predict the mechanical behaviour of the composites up to failure to aid the design of these materials. Using both analytical, micromechanical finite element models and experimental methods, this work also allows investigation of the relationship between the microstructure and mechanical properties.

Modelling the damage and deformation process in a plastic bonded explosive microstructure under tension using Finite Element method

Modelling the damage and deformation process in a plastic bonded explosive microstructure under tension using Finite Element method



Image based FE models for modelling fracture of high volume fraction particulate composite. The model is reconstructed from scan image data obtained using a Scanning Electron Microscope.
Image based FE models for modelling fracture of high volume fraction particulate composite. The model is reconstructed from scan image data obtained using a Scanning Electron Microscope.

Image based FE models for modelling fracture of high volume fraction particulate composite. The model is reconstructed from scan image data obtained using a Scanning Electron Microscope.
Image based FE models for modelling fracture of high volume fraction particulate composite. The model is reconstructed from scan image data obtained using a Scanning Electron Microscope.

Paints and coatings

Mechanics of paints: constitutive models and crack formation models in painted works of art

Soratos Tantideeravit, Eric Hagan, Daniel Balint, Christina Young & Maria Charalambides

 The group has a history of research into the mechanics of paints including micromechanical models for modern paints (acrylics) as well as predicting  lifetime in painted works of art due to changes in environmental storage conditions in museums.

One objective of these studies is to model the effect of low amplitude cyclic stresses on multilayer paint systems found in works of art. Peel tests were performed to determine the cohesive zone properties of the paint interface. A finite element model of a coating on a primed canvas substrate was subjected to combined cyclic and static mechanical loadings typically experienced by fine art paintings. Interface separation was controlled by an irreversible cohesive zone model that includes damage accumulation due to cyclic loading. Fatigue crack initiation times in years were predicted for various conditions including ordinary and extreme histories that paintings may experience in museum and conservation settings. The work is about to be extended in a new collaborative study with the University of Glasgow (Christina Young) based on understanding and predicting crack formation in painted wooden cultural heritage.

Prediction of Delamination in Multilayer Artist Paints under Low Amplitude Fatigue Loading

Prediction of Delamination in Multilayer Artist Paints under Low Amplitude Fatigue Loading



Mechanics of paintsMechanics of paints

Adhesives

Cohesive zone models for pressure sensitive adhesives in medical applications

Maria Charalambides, Anthony Kinloch, Idris Kevin Mohammed

The aim of this research was to design and develop a drug loaded patch for the treatment of nail fungal infections. It included determining the optimal backing membrane/pressure sensitive adhesive (PSA) combination with good mechanical and adhesive properties for application to the nail plate. To mimic the removal of a patch from a nail, fixed arm peel experiments were performed at different angles, speeds and substrates and subsequently modelled using the finite element method.

Modelling the Interfacial Peeling of Pressure-Sensitive Adhesives

Modelling the Interfacial Peeling of Pressure-Sensitive Adhesives

Peeling

Shear Dynamic Mechanical Analysis of a pressure-sensitive adhesive and a schematic of the peeling model with the four main components
Shear Dynamic Mechanical Analysis of a pressure-sensitive adhesive and a schematic of the peeling model with the four main components

Material modelling

Rheological modelling for soft solids

Inherent in all the studies of the group is to determine the correct constitutive law for the soft polymeric material, whether this is a matrix in a particulate composite such as paints or a consumer product such as food (the team has studied several foods such as cheese, doughs, gels, cheese). The group has therefore built up a considerable expertise in mechanical characterisation of such compliant materials as well as constitutive modelling. Experiments are complicated due to the soft nature of the material which excludes the use of standard methods derived for structural solid polymers. Rheological models are complex due to the highly non-linear, large strain,  time dependent behaviour often also accompanied by damage/irreversible flow and/or poroelasticity.

Modelling and Experimental Characterisation of the Rate Dependent Fracture Properties of Gelatine Gels

Modelling and Experimental Characterisation of the Rate Dependent Fracture Properties of Gelatine Gels

Rheological modelling

Soft solids impact

Experimental and numerical investigation of soft impact loading on aircraft materials

Jie Zhou, Iman Mohagheghian, Gordon Williams, John DearMaria Charalambides

Figure 1: gas gun test set-up
Figure 1: gas gun test set-up



Figure 2: Simulation methods are used to predict the bird strike and compared with gas gun experimental gas gun test
Figure 2: Simulation methods are used to predict the bird strike and compared with gas gun experimental gas gun test

Figure 3:  Comparison between experimental observations and numerical simulation predictions
Figure 3: Comparison between experimental observations and numerical simulation predictions

Plastics Recycling

Mechanical Recycling of multilayer packaging materials (MLP)

Investigators: Daniel Balint, Bamber Blackman, Maria Charalambides, Soraia Pimenta, Ambrose Taylor. PDRA: Manu Charles Mulakkal

The group has a strong track record of renowned research into complex multiphasic materials and their microstructural characterisation, and adhesion. The expertise in these fields are now applied to help solve one of the pressing societal challenges that we face today - Plastic pollution. Multilayer packaging (MLP) films are utilised predominantly in food industry to extend the shelf life of food articles and they combine the merits of different functional materials in a single laminate form, thus performing a myriad of functions such as mechanical support, gaseous barrier, light barrier, sealability and printability for communication and brand identity. Currently, these packaging materials are landfilled or incinerated after their use as there are many inherent challenges that needs to be addressed to enable their recycling.  The group’s research activities in this space includes developing material models to predict the mechanical properties of recycled MLP from combined melt processing. These material models can offer a virtual testing platform on which optimisation of recycled materials and their mechanical properties can be efficiently performed, greatly reducing the need for alternative trial-and-error approaches. Additionally, tapping into the group’s extensive experience on adhesion, new recycle friendly multilayer packaging designs are also being investigated to mitigate the challenges limiting the recyclability of MLP while preserving the value of recycled materials from MLP.

MLP
