Sand pack LV60C

Download image (binary and ASCII) : The image binary file (*.raw) can used for viewing the subsection of the Micro CT image used for the network extraction, this binary file can be viewed by using ImageJ software. The network is extracted from the image ASCII file (*.dat) using the network extraction code.

Download Network and results summary: The results summary contains the type and name of the sample, size of the image in voxels, the image resolution (voxel edge size), porosity, permeability and formation factor. The permeabilities and formation factors were computed on both voxelized images and pore networks.  The network can be viewed using Rhino Modelling Software, the steps involved in viewing the network can be downloaded from (Viewing Networks).
